• iMat-Vending
iMat-Vending iMat-Vending iMat-Vending iMat-Vending

iMat-Vending

whatsApp Us
+ Add to wishlist

MODEL : S50-80 Plus


Essential Information
Product Name iMat®️Vending-80 Plus (Coil Vending Machine)
Model Number S50-80 Plus
Product Features
Flexible channel : Support customized and post-factory configuration springs according to customer needs
The cutting tool is temporarily stored, with its own independent slot, and the recycling port is configured for waste and old cutting tools respectively
The cutting tool can be replaced by the old one
Product Parameters
Whole Size 1950*1190*845mm
Single channel size 175*165(W*D)
Channel Cpacity Spring channel (80);Locker channel (15)
Weight 350kg
Max manangeable cpacity 1840
Voltage 100~240V AC
Power 100W
Collection Method Swipe card / QR code / password

MODEL : S50-80


Essential Information
Product Name iMat®️Vending-80 (Coil Vending Machine)
Model Number S50-80 Plus
Product Features
The cutting tool can be replaced by the old one
The cutting tool is temporarily stored, with its own independent slot, and the recycling port is configured for waste and old cutting tools respectively
Flexible channel: Support customized and post-factory configuration springs according to customer needs
Product Parameters
Whole Size 1950*1190*845mm
Single channel size 75*165(W*D)
Capacity Type 80
Load capacity of single channel 5kg
Max manangeable cpacity 1840
Voltage 100~240V AC
Power 100W
Collection Method Face recognition / card swipe / QR code / password
Managing Materials
1. Bearing drive
2. Electrical auxiliary materials
3. Abrasives

MODEL : S50-48


Essential Information
Product Name iMat®️Vending-48（Spiral Smart Mini-warehouse）
Model Number S50-80 Plus
Product Features
Automatic door opening after settlement
Settlement with error-proof and leak-proof function
Support differential setting of employee permissions
Lifting platform for tool protection
Support tool trade-in and recycling of used tools
Product Parameters
Whole Size 1950*1050*860mm
Single Size Width 75mm, can be configured with 3/4/5/6/7/8/10/12/15/16/17/18/20/21 section springs
Capacity Type 48
Screen 21.5
Weight 300kg
Voltage 220V AC
Power 100W
Collection Method Face recognition / card swipe / QR code / password
Managing Materials
1. Power Transmission
2. CNC tools
3. Power Transmission
4. Abrasives
5. Abrasives
6. Fragile MRO supplies
7. cutting tools
8. Welding supplies

MODEL : S30-48


Essential Information
Product Name iMat®️Vending-48（Spiral Smart Mini-warehouse）
Model Number S30-48
Product Parameters
Whole Size 1880*1000*860mm
Single Size Width 75mm, can be configured to use 5/6/7/8/10/12/15/16/17/18/19 section springs
Capacity Type 48
Screen 21.5
Weight 230kg
Voltage 220V AC
Power 100W
Collection Method Swipe Card
